Chapter 14 Appendix RIGOL
User’s Guide for DG5000
14-5
Analog Voltage Range
1.4～9.4V
Bit Order MSB
Clock (CLK) Line
D0～D15 (selectable)
Data (SDA) Line
D0～D15 (selectable)
CS Line
D0～D15 (selectable)
Transmission Rate
1bps～60Mbps (adjustable)
Output Data Range
1Byte～40k Bytes (selectable)
Clock Polarity 0 and 1 (selectable)
Clock Phase 0 and 1 (selectable)
CS Level Low level and high level (selectable)
Data per Frame (#Data)
1～3Bytes
Parameters and Specifications relating to RS232 Protocol
Analog Voltage Range
2.0V～4.5V -4.5V～-2.0V
Bit Order LSB
Data Line (TX)
D0～D15 (selectable)
Transmission Rate
1Bps～60MBps (adjustable)
Output Data Range
1Byte～35k Bytes (selectable)
Data per Frame (#Data)
5～8bits
Verify Mode None, Fixed0, Fixed1, Odd, Even
Stop Bit 1bit, 1.5bit and 2bits
