Leading/
Trailing Edge
Time
Typical Value
(1Vpp, 50Ω)
2.5 ns to 1 ms
Typical Value
(1Vpp, 50Ω)
2.5 ns to 1 ms
Typical Value
(1Vpp, 50Ω)
3 ns to 1 ms
Typical Value
(1Vpp, 50Ω)
4 ns to 1 ms
Overshoot Typical Value (1Vpp)
<5%
Jitter (rms) Typical Value (1Vpp)
10 ppm+500 ps
Arb
Waveform
Length
Normal Mode: 2 to 16M points
Play Mode: 2 to 128M points
Vertical
Resolution
14 bits
Mode Normal Mode, Play Mode
Sample Rate Normal Mode (Waveform Length is from 2 to 16M points): 1G Sa/s (fixed);
Play Mode (Waveform Length is from 2 to 128M points): ≤1G Sa/s (variable)
Minimum
Rise/Fall Time
Typical Value (1Vpp)
≤3 ns
Jitter (rms) 3 ns
Interpolation
Method
Close, Linear, Sinc
Edit Method Edit Point, Edit Block
Non-Volatile
Memory
1G Bytes
Output Characteristics
Amplitude (into 50 Ω)
Range ≤100MHz:
5mVpp to 10Vpp
≤300MHz:
5mVpp to 5Vpp
≤350MHz:
5mVpp to 2Vpp
≤100MHz:
5mVpp to 10Vpp
≤250MHz:
5mVpp to 5Vpp
5mVpp to 10Vpp 5mVpp to 10Vpp
