User’s Guide for DS1000 Series
The waveform is displayed as Figure 2-4:
Figure 2-4
Press CH1→Coupling→GND, to set coupling as “GND” of CH1. In this setting, it
disconnects the input signal.
The screen displays as Figure 2-5:
Figure 2-5
GND coupling
setup
GND coupling
status symbol
DC coupling
setup
DC coupling
status symbol
