Robopac Masterplat PLUS TP3 PGS - Replacing the Rotary Table Wheels

115
REPLACEMENT INFORMATION
ENG
9.2. REPLACING THE ROTARY TABLE WHEELS
1. Loosen the screws (A).
2. Fit the eyebolts (B) and remove the upper plate (C).
3. Lift the table and place it on the ground.
4. Replace the wheels (D).
5. Reposition the table on the base and fasten it with the screws.
Masterplat PLUS LP
Masterplat PLUS TP3
