Robopac Masterplat PLUS TP3 PGS - Replacing the Rotary Table Gear Wheels

ENG
REPLACEMENT INFORMATION
118
9.5. REPLACING THE ROTARY TABLE GEAR WHEELS
1. Remove the cover (A).
2. Loosen the fastening screws (D) of the gear wheels (B) and (C).
3. Replace the gear wheels.
Danger - warning
Any maintenance operation in this area must be carried out with machine stopped, with electric switch set
to OFF and with no other operator near the machine.
Masterplat PLUS LP
