Robopac Masterplat PLUS TP3 PGS - Masterplat PLUS FRD Machine and Pallet Dimensions; Masterplat PLUS PGS Machine and Pallet Dimensions

39
TECHNICAL INFORMATION
ENG
3.7.1. "MASTERPLAT PLUS FRD" MACHINE AND PALLET DIMENSIONS
Description
Masterplat PLUS FRD
Standard
Optional
Optional
Optional
Shaft height
2200
2400
2800
3100
A
H
2530
2730
3130
3430
B
2560
2760
3160
3460
H1
2200
2400
2800
3100
M
77.5
77.5
77.5
77.5
Load overall
dimensions
 1650
 1800
-
-
C
1650
1800
-
-
D
2760.5
2835.5
-
-
E
1715
1790
-
-
F
G
N
L
1000
1200
-
-
W
1200
1200
-
-
Weight (kg)
2000
2000
-
-
3.7.2. "MASTERPLAT PLUS PGS" MACHINE AND PALLET DIMENSIONS
Description
Masterplat PLUS PGS
Standard
Optional
Optional
Optional
Shaft height
2200
2400
2800
3100
A
H
2865
3065
3465
3765
B
2560
2760
3160
3460
H1
2200
2400
2800
3100
M
77.5
77.5
77.5
77.5
Load overall
dimensions
 1650
 1800
-
-
C
1650
1800
-
-
D
2760.5
2835.5
-
-
E
1745
1820
-
-
F
G
N
L
1000
1200
-
-
W
1200
1200
-
-
Weight (kg)
2000
2000
-
-
