TECHNICAL INFORMATION
ENG
3.5. DESCRIPTION OF PNEUMATIC DEVICES
The figure shows the position of the devices on the machine.
1. Pressure regulator with filter and pressure gauge
To adjust the general pressure of the pneumatic system.
Turn the knob to change the pressure values indicated on the pressure gauge.
Important
For further details see the pneumatic diagram.
