Robopac Masterplat PLUS TP3 PGS - Manual Controls

ENG
INFORMATION ABOUT THE USE
84
6.4.5. MANUAL CONTROLS
Activation
mode
abbreviation
Button
Description
P
Press the button (5) to access the “Manual controls” Menu.
Activation
mode
abbreviation
Button
Description
R
If “JOG” is pressed, the carriage (hold to run) rises until reaching the upper limit
switch
R
If “JOG” is pressed, the presser (hold to run) rises until reaching the upper
position
R
If “JOG” is pressed, the table (hold to run) turns until reaching the initial position
R
If “JOG” is pressed, the presser (hold to run) moves down until reaching the
lower position
R
If “JOG” is pressed, the carriage (hold to run) moves down until reaching the
lower limit switch
R
Return to the previous menu
