INFORMATION ON ADJUSTMENTS
ENG
5.7. ADJUSTING THE TABLE GUIDE WHEELS
1. Remove the cover (A).
2. Loosen the fastening nuts (B).
3. Loosen the screw (E).
4. Tighten the screw (D) so that the wheel (C) is pressed against the rotary plate by approximately 4 mm.
5. Tighten the screw (E).
6. Tighten the nuts (B).
7. Refit the guard (A).
