Robustel R3000 Quad User Guide
RT_UG_R3000 Quad_v.3.0.0 28 May, 2017 42 / 131
Confidential
You may click to edit the configuration of the LAN port, or click to delete the current LAN port. Now, click to
add a new LAN port.
Indicate the ordinal of the list.
Show the editing port. Lan1 is available only if it was selected by one of
ETH0~ETH3 in Ethernet > Ports > Port Settings, and so on.
Set the IP address of the LAN port.
Set the Netmask of the LAN port.
Enter the Maximum Transmission Unit.
The window is displayed as below when choosing “Server” as the mode.
