Rockwell Automation Publication 1715-UM001J-EN-P - December 2020 249
Appendix A Status Indicators
Table 54 - Adapter Status Indicators
Indicator State Description
Module Status
Steady off No power - There is no power to the module.
Steady green
Module operational - The module has been
configured without any faults.
Flashing green Standby - The module has not been configured.
Flashing red (with steady red for network status) An address conflict has been detected.
Flashing red (with flashing green for network status)
Module firmware is being updated with
ControlFLASH™
Flashing red (with NOT steady red and NOT flashing
green for network status)
Recoverable fault detected.
Steady red
Major fault - The module has detected a
nonrecoverable fault.
Flashing green/red
Self-test - The module is performing its power-on
self-tests.
Flashing amber
Unlocked - Adapter is unlocked from a previously
locked state.
Redundancy Status
Steady off
No power, unlocked, or no partner - The module is not
locked (via the locking screw), or no partner module
is present.
Steady green
Synchronized - The module is synchronized with the
partner module (redundant operation).
Flashing green
Partner detected, synchronizing - The partner
module has been detected and is synchronizing with
its partner module in preparation for redundant
operation.
Steady red
Synchronization fault - The partner module is
present, but unable to synchronize (no redundant
operation).
Flashing green/red
Self-test - The module is performing its power-on
self-tests.
Flashing amber
Unlocked - Adapter is unlocked from a previously
locked state.
Network Status
Steady off
No power, unlocked, no IP address - The module has
no power, or the module is not locked (via the locking
screw), or no IP address has been assigned or
obtained.
Steady green
Connected - The module has at least one established
connection (either to itself or to an
I/O module).
Flashing green
No connections - The module has an IP address, but
there are no established connections (either to itself
or an I/O module).
Flashing red
Connection timeout - One or more of the connections
(either to itself or to an I/O module) has timed out.
Steady red
Duplicate IP - The module has detected that its IP
address is already in use.
Steady red (with flashing red for module status) An address conflict has been detected.
Flashing green/red
Self-test - The module is performing its power-on
self-tests.
Flashing amber
Unlocked - Adapter is unlocked from a previously
locked state.
Rack Status
Steady off
No power, unlocked - The module has no power or it
is not locked (via the locking screw).
Steady green
Rack operational - All modules in the rack are
operating without fault.
Steady red
Fault - At least one module in the rack has detected a
fault. Examine the other modules in the rack for their
status indicator condition.
Flashing green/red
Self-test - The module is performing its power-on
self-tests.
Flashing amber
Unlocked - Adapter is unlocked from a previously
locked state.
