Rockwell Automation Allen-Bradley Kinetix 5300 Migration Guide

12 Rockwell Automation Publication 2198-RM005A-EN-P - October 2020
Chapter 1 Replacement Considerations
Circuit Breaker and Fuse Considerations
Review the fusing requirements when you change a drive.
Table 6 - Kinetix 350 Drive Fuse and Circuit Breaker (CB) Specifications
Drive Cat. No. Drive Voltage Phase
UL Applications IEC (non-UL) Applications
Fuses
(Bussmann)
Miniature CB
Cat. No.
Motor
Protection CB
Cat. No.
DIN gG
Fuses
Amps (max)
Miniature CB
Cat. No.
Motor
Protection CB
Cat. No.
2097-V31PR0-LM 120/240V Single-phase KTK-R-10 (10 A) 1489-M1C100 140M-C2E-C10 10 1492-SPM1D100 140M-C2E-C10
2097-V31PR2-LM 120/240V Single-phase KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 20 1492-SPM1D200 140M-D8E-C20
2097-V32PR0-LM 240V Single-phase KTK-R-15 (15 A) 1489-M1C150 140M-D8E-C16 16 1492-SPM1D150 140M-D8E-C16
2097-V32PR2-LM 240V Single-phase KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 20 1492-SPM1D200 140M-D8E-C20
2097-V32PR4-LM 240V Single-phase KTK-R-30 (30 A) 1489-M1C300 140M-F8E-C32 32 1492-SPM1D320 140M-F8E-C32
2097-V33PR1-LM
120/240V Single-phase KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 20 1492-SPM1D200 140M-D8E-C20
240V Three-phase KTK-R-15 (15 A) 1489-M3C150 140M-D8E-C16 16 1492-SPM3D150 140M-D8E-C16
2097-V33PR3-LM
120/240V Single-phase KTK-R-20 (20 A) 1489-M1C200 140M-D8E-C20 20 1492-SPM1D200 140M-D8E-C20
240V Three-phase KTK-R-15 (15 A) 1489-M3C150 140M-D8E-C16 16 1492-SPM3D150 140M-D8E-C16
2097-V33PR5-LM
120/240V Single-phase KTK-R-30 (30 A) 1489-M1C300 140M-F8E-C32 32 1492-SPM1D300 140M-F8E-C32
240V Three-phase KTK-R-20 (20 A) 1489-M3C200 140M-D8E-C20 20 1492-SPM3D200 140M-D8E-C20
2097-V33PR6-LM
120/240V Single-phase LPJ-40SP — 140M-F8E-C32 40 — 140M-F8E-C32
240V Three-phase KTK-R-30 (30 A) 1489-M3C300 140M-F8E-C32 32 1492-SPM3D300 140M-F8E-C32
Table 7 - Kinetix 5300 Drive Fuse and Circuit Breaker (CB) Specifications
Kinetix 5300 Drives UL Applications IEC (non-UL) Applications
Drive Cat. No. Drive Voltage Phase
Fuses
(Bussmann)
Molded Case CB
Cat. No.
DIN gG Fuses
Amps (max)
Miniature CB
Cat. No.
Molded Case CB
Cat. No.
2198-C1004-ERS
110V Single-phase KTK-R-6
140U-D6D2-B40
6
1489-M2C060 140U-D6D2-B40
230V
Single-phase KTK-R-6
Three-phase KTK-R-6 140U-D6D3-B40 1489-M3C060 140U-D6D3-B40
2198-C1007-ERS
110V Single-phase KTK-R-10
140U-D6D2-B80
10
1489-M2C100 140U-D6D2-B80
230V
Single-phase KTK-R-10
Three-phase KTK-R-10 140U-D6D3-B80 1489-M3C100 140U-D6D3-B80
2198-C1015-ERS
110V Single-phase KTK-R-15
140U-D6D2-C12
16
1489-M2C160 140U-D6D2-C12
230V
Single-phase KTK-R-15
Three-phase KTK-R-15 140U-D6D3-C12 1489-M3C160 140U-D6D3-C12
2198-C1020-ERS
110V Single-phase KTK-R-25
140U-D6D2-C20
25
1489-M2C250 140U-D6D2-C20
230V
Single-phase KTK-R-25
Three-phase KTK-R-25 140U-D6D3-C20 1489-M3C250 140U-D6D3-C20
2198-C2030-ERS 230V Three-phase KTK-R-30 140U-D6D3-C30 32 1489-M3C400 140U-D6D3-C30
2198-C2055-ERS 230V Three-phase LPJ-50SP 140G-G6C3-C50 40 – 140G-G6C3-C50
2198-C2075-ERS 230V Three-phase LPJ-60SP 140G-G6C3-C60 50 – 140G-G6C3-C60
2198-C4004-ERS 480V Three-phase KTK-R-3 140U-D6D3-B20 2 1489-M3C030 140U-D6D3-B20
2198-C4007-ERS 480V Three-phase KTK-R-6 140U-D6D3-B40 6 1489-M3C060 140U-D6D3-B40
2198-C4015-ERS 480V Three-phase KTK-R-12 140U-D6D3-B80 12 1489-M3C100 140U-D6D3-B80
2198-C4020-ERS 480V Three-phase KTK-R-15 140U-D6D3-C12 16 1489-M3C130 140U-D6D3-C12
2198-C4030-ERS 480V Three-phase KTK-R-25 140U-D6D3-C15 25 1489-M3C200 140U-D6D3-C15
2198-C4055-ERS 480V Three-phase LPJ-30SP 140U-D6D3-C30 32 1489-M3C350 140U-D6D3-C30
2198-C4075-ERS 480V Three-phase LPJ-35SP 140U-D6D3-C30 32 1489-M3C400 140U-D6D3-C30
