Rockwell Automation Allen-Bradley LiquiFlo 2.0 - AC Line I;O Board Description (Frame 3 Only)

144 Rockwell Automation Publication D2-3518-4 - January 2020
Chapter 9 Parameter Descriptions
Sets the user-configurable analog output value when the source value is at
minimum. See Analog Out1 Hi (343) for more information. See AC Line I/O
Board Description (Frame 3 Only) on page 25 through Combined I/O Board
Description (Frame 4 Only) on page 29 for a description of I/O hardware that is
present on this drive and is controlled by the inverter.
Displays the measured temperature of the top inverter IGBT power module in
degrees C.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
Displays the measured temperature of the upper inverter IGBT power module
in degrees C.
This parameter is only present on Frame 4 drives. All such drives should have
firmware version numbers in the 2.x series.
Displays the measured temperature of the lower inverter IGBT power module
in degrees C.
344
Analog Out1 Lo
Range: 4.000...20.000 mA [0.001 mA]
-/+10.000V [0.1V]
0.0...10.000V [0.1V]
Default: 4.0 mA
Access: 0 Path: Inputs & Outputs > Analog Outputs
See also: 31, 342, 343
345
Inv IGBT Tmp Top
Range: -3276.8...3276.7 °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also: 346, 347, 348
346
Inv IGBT Tmp Up
Range: -3276.8...3276.7 °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also: 345, 347, 348
347
Inv IGBT Tmp Low
Range: -3276.8...3276.7 °C
Default: Read Only
Access: 1 Path: Inputs & Outputs > Temperature etc
See also: 345, 346, 348
