Replacement Parts
Tab le 3 1 through Tabl e 34 list the available replacement parts.
Replacement Parts (Frame 3 Drive)
Table 31 - LiquiFlo 2.0 Drive Replacement Parts (Frame 3 Only)
Description Part Number / Kit Number Quantity
Frame 3AA Frame 3CC
180264-A03 180264-A06
AC Contactor - 140 A, 120 V 100-140D11 3 3
AC Contactor (surge suppresor) 110V, 127V 100-DFSC110 3 3
Capacitor Bank Assembly 21T-LCL-CB9
21T-LCL-CB7
1
-
-
1
Line Sync. PC Board Assembly 21T-180043 1 1
Line Sync. Board Cover 21T-179723 1 1
Fuse Block, 30 A, 600 V, Class CC, 2-Line 49454-19B 1 1
Fuse Block, 30 A, 600 V, Class CC, 3-Line 49454-19C 2 2
Lug, 2-600 MCM Thomas & Betts # ADR60-22D 1 1
115 V Fan, 6” dia. SK-L1-FAN3-F3 2 2
Transformer, 5 kVA 21T-MISC-B-TR1 1 1
Fuse Holder, 600 V, 30 A Buss # R60030-2SR 1 1
Precharge Resistor, 47 Ohm, 300W 21T-322542-A02 (set of 3 resistors) 3 3
Resistor, 100 kOhm, 50 W Dale # RH-50 3 3
Circuit Breaker, Main (Qty 1)
65kAIC (base drive = 1)
100kAIC (option = O)
21P-CB-A600-65-S
21P-CB-A600-100-S(100kAIC)
21P-CB-A800-65-S
21P-CB-A800-100-S(100kAIC)
21P-CB-A600-HDL (Handle)
1
O
-
-
1
-
-
1
O
1
Fuse, Class RK-5, 600 V, 15 A Gould/Shawmut # TRS-R15 2 2
Fuse, Class CC, 600 V, 5 A Gould/Shawmut # ATQR5 1 1
Fuse, Class CC, 600 V, 1 A Gould/Shawmut # ATQR1 3 3
Fuse, Class CC, 600 V, 20 A Gould/Shawmut # ATDR20 3 3
Fuse, Class CC, 600 V, 25 A Gould/Shawmut # ATQR25 1 1
Terminal Block, 6-Position 49455-93E 1 1
Capacitor Guard Panel 179960 1 1
Plastic Knob Reid # JCL-555 4 4
460 A Power Module LF200460AAR 1 -
608 A Power Module LF200608CCR - 1
LCD OIM, Door-Mounted RE1LCD
REBZL-N1
1
1
1
1
Air Filter 180415 1 1
Floor Mounting Kit (Optional) 180380-Q01 3 3
Surge Suppressor 21T-385253-A04 1 1
Inductor, 405 Amp 21T-380097-A02 1 -
Inductor, 610 Amp 21T-380097-A04 - 1
