Rockwell Automation Publication 750-RM004A-EN-P - April 2018 111
Drive Configuration Chapter 2
PowerFlex 700S DriveLogix
5730 Configurations
The PowerFlex 700S Phase II drive could be equipped with an optional
DriveLogix 5730 processor, catalog 20D-DL2-LEB0. The DriveLogix 5730
Logix Expansion board requires the expanded cassette.
DriveLogix offers embedded Logix control for application programmability
and control of auxiliary functions in the PowerFlex 700S. DriveLogix is
programmed using Studio/RSLogix 5000. It is a fully functional
CompactLogix™ controller. It can be programmed using a Ladder Diagram,
Function Block Diagram, Sequential Function Chart, or Structured Text. It is
only an option for the PowerFlex 700S and is not available in any other current
drive product. More information on DriveLogix can be found in the
DriveLogix 5730 Controller for PowerFlex 700S Drives with Phase II Control
User Manual, publication 20D-UM003
.
As previously mentioned, the initial release of PowerFlex 755T firmware
excludes the DeviceLogix™ application. DeviceLogix is an embedded control
technology in some Rockwell Automation products that can control outputs
and manage status information onboard a device. In the PowerFlex 755,
DeviceLogix is used to provide additional control capability at the drive level
based on application needs. A Function Block Diagram or Ladder Logic
program can be configured to control drive functions and physical and
networked I/O. DeviceLogix is programmed using Connected Components
Workbench (CCW). More information on DeviceLogix is found in the
DeviceLogix System User Manual, publication RA-UM003
.
Migration Solutions
It will be necessary use an external automation controller, such as a
CompactLogix or ControlLogix®, and translate your PowerFlex 700S
DriveLogix application software to operate within the automation controller.
A communication network is required to communicate between the PowerFlex
755T and the automation controller.
