Enclosure Information Appendix A
Figure 51 - PowerFlex 700S Frame 10…12 IP20 MCC Enclosure, Minimum Clearances
PowerFlex 755T Product Installation Requirements
Environmental Conditions
• Elevation above sea level without derating must be less than 1000 m
(3250 ft).
• Ambient air temperature without derating must be between
-20…+40 °C (-4…+104 °F).
• Relative humidity must be less than 95%, noncondensing.
• The product must be installed indoors; there must be no dripping water
or other fluids in the room.
• Cooling air must be clean without significant concentrations of sand,
corrosive or conductive dust (defined by IEC 721-1 as being less than
0.2 mg/m
3
of dust), or explosive gas.
• Free from significant vibration.
200 mm
(7.87 in.) Min.
Powerful Performance, Flexible Control.
838 mm
(33.0 in.) Min.
