Rockwell Automation Publication 750-RM004A-EN-P - April 2018 61
Selection Considerations Chapter 1
DC Input Dimensional Cross
Reference
Table 2 9 through Table 32 compare approximate dimensions of DC input
PowerFlex 700S drives and DC input PowerFlex 755TM common bus
inverters. Shaded rows in the table indicate an acceptable cross-reference unless
noted otherwise. Outline dimensional drawings are shown in Appendix A on
page 121.
Because it is impossible to predict the combinations of hardware that could be
used in the existing PowerFlex 700S drive configuration, these tables only
consider migration solutions based on published catalog ratings for the
PowerFlex 700S drives.
IMPORTANT The PowerFlex 700S frame 9 drive is usually mounted within an enclosure,
however, it can be wall-mounted per the catalog numbers shown. The
equivalent PowerFlex 755TM common bus inverter is supplied as a floor
standing enclosure. Consider the mounting and enclosure types that are
used for your PowerFlex 700S frame 9 migration solution to ensure the
PowerFlex 755TM enclosed common bus inverter can be installed in the
available space.
