Appendix A Enclosure Information
DC Input Dimensions
DC input frames 9…13 PowerFlex 700S drives have the same dimensions as
AC input frames.
Figure 44 - DC Input Frame 14 PowerFlex 700S
2232
(88)
601
(23.7)
620
(24.5)
44
(1.7)
2270
(89.4)
1597
(63.0)
675
(26.6)
125 (5.0)
62.25
(2.5)
475
(18.7)
65
(2.6)
30 (1.2)
68.75 (2.7)
799.5 (31.5)
675
(26.6)
Dimensions are in millimeters and (inches).
DC Input
