Rockwell Automation Allen-Bradley PowerFlex 700S Migration Guide

Rockwell Automation Publication 750-RM004A-EN-P - April 2018 143
Enclosure Information Appendix A
Minimum Clearances
Specified vertical clearance requirements are intended to be from the product
to the closest object that can restrict airflow through the cabinet. The product
must be mounted in a vertical orientation as shown and must make full contact
with the mounting surface. Inlet air temperature must not exceed the product
specification.See Table 10 on page 40
.
Figure 52 - Minimum Overhead Clearances
200 mm
(7.9 in.)
250 mm
(9.8 in.)
IP21, UL Type 1 IP54, UL Type 12
