Chapter 1 Selection Considerations
IP54, NEMA/UL Type 12
Approximate dimensions exclude
fan housings, handles, and so on.
Dimensions (H x D), Approx. (width
varies).
Rittal
2400 x 600 mm (94.5 x 23.6 in.)
See publication 20D-TD002 for
detailed dimensional data.
Rittal
2000 x 600 mm (78.7 x 23.6 in.)
See publication 750-TD101 and
publication 750-IN101 for detailed
dimensional data.
Input Cable Entry (s), IP21 Rittal, Bottom only
(s), IP20 2500 MCC, Top only
(s) Bottom all frames
(s) Top frames 8…9, specify power
option (-P17) w/o wiring bay
(o) Top, frames 10…12, specify
power option (-P16) w/ wiring bay
DC Power Bus — PowerFlex 755TM CBI;
(s) frames 8…10, 3000 A DC
(s) frames 11…12, 4700 A DC
(o) frames 8…10, 4700 A DC specify
power option code (-P46)
Near top/back, horizontal busbars,
side exit
Control Power Bus — (s) 240V AC, 1 PH, 100 A rms
(s) 24V DC Auxiliary Control Bus,
100 A DC
(s) 120/240V AC, 1 PH, User Control
Bus, 100 A rms
Control Bus Connector taps are rated
10 A per pole.
Table 10 - Environmental Features
Description PowerFlex 700S, Frames 9…14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, Frames 8…12
Cat. No. 20D… Cat. No. 20G…
Environmental Compliance See Rockwell Automation website at;
https://www.rockwellautomation.com/global/about-us/sustainability-
ethics/product-environmental-compliance.page
Altitude
(Without Derate)
1000 m (3000 ft)
See Technical Data, publication 20D-
TD002 for detailed derating
information.
1000 m (3000 ft)
See Technical Data, publication 750-
TD100 for detailed derating
information.
Ambient Temperature Range
(Without Derate)
0…40°C (32…104°F), depends on
voltage and rating.
0…35°C (32…95°F), depends on
voltage and rating.
See Technical Data, publication 20D-
TD002 for detailed temperature
derating information.
-20…+40°C (-4…+104°F), all
frame ratings and enclosure types.
See Technical Data, publication 750-
TD100 for detailed temperature
derating information.
Storage Temperature -40…+70°C (-40…+158°F) -40…+70°C (-40…+158°F)
Relative Humidity (Noncondensing) 5…95% 5…95%
Table 9 - Enclosure Features (Continued)
Description PowerFlex 700S, F9…F14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, F8…F12
Cat. No. 20D… Cat. No. 20G…
