Rockwell Automation Publication 750-RM004A-EN-P - April 2018 41
Selection Considerations Chapter 1
Mechanical Shock Non-operational;
15G peak for 11 ms duration (+/-
1ms), EN50178 / EN60068-2-27
Operating; not specified
Packed for shipment;
Meets ATSM International standards
Operating (packaged products);
10G peak for 11 ms duration (+/-1
ms), three shocks in each direction
in each axis. See the Shock Events
information in the Technical Data,
publication 750-TD100
for detailed
information about the maximum
number of shock events.
Mechanical Vibration Non-operational; not specified
Operating;
2 mm (0.0787 in.) displacement, 1G
peak, EN50178 / EN60068-2-6
Packed for shipment;
Meets ATSM International standards
Operating;
1 mm (0.040 in.) displacement, 1G
peak
Sound At 1 m (3.28 ft)
Frame 9, 78 dB
Frame 10, 77 dB
Frame 11, no data
Frame 12, no data
Frame 13, 76 dB
At 2 m (6.6 ft)
PowerFlex 755TL and 755TR, IP21 /
IP54;
• Frame 8, 79 / 78 dBA
• Frame 9, 81 / 80 dBA
• Frame 10, 84 / 83 dBA
• Frame 11, 83 / 82 dBA
• Frame 12, 84 / 83 dBA
PowerFlex 755TM CBI, IP21 / IP54;
• Frame 8, 76 / 75 dBA
• Frame 9, 77 / 76 dBA
• Frame 10, 79 / 78 dBA
• Frame 11, 80 / 79 dBA
• Frame 12, 81 / 80 dBA
Table 11 - Certifications and Standards Compliance
Description PowerFlex 700S, Frames 9…14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, Frames 8…12
Cat. No. 20D… Cat. No. 20G…
UL UL508C (c-UL-us). UL Listing only
applicable up to 600V AC.
NFPA 70 – US NEC
NEMA
250 – Enclosures for Electrical
Equipment
UL61800-5-1 (c-UL-us) only
applicable up to 600V AC
CAN/CSA CSA 22.2 No. 14-05 CSA 22.2 No. 274, Adjustable Speed
Drives
CE Marked for following European
Directives:
• EMC Directive (2004/108/EC) EN
61800-3:2004 Adjustable speed
electrical power drive systems –
Part 3: EMC requirements and
specific test methods.
• Low Voltage Directive (2006/95/
EC) EN 50178:1997.
In conformity with the following
European Directives:
• EMC Directive (2014/30/EU)
• Low Voltage Directive (2014/35/
EU)
• RoHS Directive (2011/65/EU)
Standards applied:
• EN 61800-3
• EN 61800-5-1
(o) Additional EMI filter available,
choose catalog code (-J) for EMC
filter selection.
Table 10 - Environmental Features (Continued)
Description PowerFlex 700S, Frames 9…14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, Frames 8…12
Cat. No. 20D… Cat. No. 20G…
