92 Rockwell Automation Publication 750-RM004A-EN-P - April 2018
Chapter 2 Drive Configuration
Parameter Comparison
Use Table 5 2 through Table 58 to cross-reference commonly used and
modified PowerFlex 700S parameters with equivalent parameters in the
PowerFlex 755TL/TR drive and PowerFlex 755TM common bus inverter.
Parameter Scaling
The PowerFlex 700S uses per unit (pu) values for most internal parameter
values and some parameters that are accessed by the user. Most parameters are
presented to the user in scaled engineering units (rpm, amps, and so on).
However, others like P10 [Speed Ref 1] and P111 [Torque Ref 1] and
presented in PU.
The PowerFlex 755T product uses floating point engineering units for all
parameter values. Confirm that Logix tags that reference PowerFlex 700S PU
parameters are properly scaled for use with the PowerFlex 755T product.
PowerFlex 700S Parameter Assignment
The PowerFlex 700S uses linear parameter numbering and direct or ‘linkable’
parameter assignments for most user parameters, so the port number is not
specified or is internally referenced to fixed port locations, like the HIM (ports
1, 2) and DPI communication (port 5).
PowerFlex 755T Parameter Assignment
The PowerFlex 755T product uses indirect parameter numbers to create
parameter assignments or to select data sources and destinations. The
maximum value for indirect parameter assignments is 159999.15.
Table 51 - PowerFlex 755T Configuration Tools
Configuration Tool PowerFlex 755T
DriveExplorer™ software Not supported
DriveTools™ SP/DriveExecutive software Not supported
Connected Components Workbench
(1)
software
(1) Separate installer update is required to use PowerFlex 755T with CCW V10.
V 10.000 and later
RSLogix 5000
Drive AOP
V 20.001 and later
V 1.0 PowerFlex 755T and later
Studio 5000
Drive AOP
V 21.003 and later
V 1.0 PowerFlex 755T and later
HIM
(2)
(2) Assisted Startup using the HIM not available at initial release.
20-HIM-A6/-C6S
