Chapter 2 Drive Configuration
Table 52 - Line Side Converter Parameters
PowerFlex 700S PowerFlex 755T
Parameter Display Name Read
/Write
Port:Parameter.Bit Display Name Read
/Write
The PowerFlex 700S does not have an active front end converter, so there are no
equivalent parameters
13:2 AC Line Voltage RO
13:6 AC Line Current RO
13:18 DC Bus Current RO
13:25 Rated Volts RO
13:26 Rated Amps RO
13:30 Nom Line Freq RW
13:32 AC Line kVA A RW
13:34 AC Line Imped% A RW
0:63 LS Start Mode
(default for 755TL/TR is (0) ‘FLW MSideInv’)
RW
0:64 LS Manual Ctrl
(If 0:63 = (2) ‘Conv Logic’, you can control
converter IGBT modulation logic, only
applies to 755TL/TR)
RW
13:45 DC Bus Ref Sel RW
13:48 DC BusRef Preset
(only used if 13:45 is set to 1 ‘Manual’
RW
13:54 Volt Reg C/U Sel RW
13:57 u Volt Reg Kp
(only used if 13:54 is set to 1 ‘User Entered’
RW
13:59 u Volt Reg Ki
(only used if 13:54 is set to 1 ‘User Entered’
RW
13:105 Motor Power Lmt RW
13:104 Regen Power Lmt RW
13:100 Current Limit RW
13:225 Line Side Sts 1 RO
14:1100 ACP0 Status RO
13:258 Alarm Status A RO
13:259 Alarm Status B RO
13:235 L Start Inhibits RO
13:240 Fault Status A RO
13:241 Fault Status B RO
