Chapter 3 Communication Configuration
PowerFlex 755T 20-COMM-x Network Adapter Compatibility
At initial release, 20-COMM-x adapters cannot be used with PowerFlex 755T
products.
Scaling of Reference and Feedback
The PowerFlex 700S drive parameters for network ‘SpeedReference’ and
‘SpeedFeedback’ data using a 20-COMM-E communication adapter are scaled
for 32767 = 1.0 PU. A Logix value of 32767 written to network DPI Port 5
‘SpeedReference’ 32-bit integer pre-defined output DataLink will equate to a
parameter P40 [Selected Spd Ref ] internal value of 1.0 PU, which is displayed
in RPM where 1.0 PU = P4 [Motor NP RPM].
Table 67 - Communication Protocol Adapter Cross-reference Guide
Protocol PowerFlex 700S
Communication
Adapters
PowerFlex 750-series Communication Modules
EtherNet/IP 20-COMM-E, 20-COMM-
ER, 1788-ENBT, 20D-DL2-
ENET0
Embedded dual-port
EtherNet/IP
20-750-ENETR dual port
User Manual, publication
750COM-UM009
User Manual, publication,
750COM-UM008
ControlNet Coax 20-COMM-C
1788-CNC/CNCR
20-750-CNETC User Manual, publication,
750COM-UM003
ControlNet Fiber 20-COMM-Q
1788-CNF/CNFR
—
(1)
(1) Future product releases may permit the use of selected 20-COMM-x communication adapters.
—
DeviceNet 20-COMM-D
1788-DNB0
20-750-DNET User Manual, publication,
750COM-UM002
HVAC Modbus RTU 20-COMM-H —
(1)
CANopen 20-COMM-K —
(1)
Modbus/TCP 20-COMM-M —
(1)
PROFIBUS DPV1 20-COMM-P 20-750-PBUS User Manual, publication,
750COM-UM004
ProfiNet — 20-750-PNET
20-750-PNET2P
User Manual, publication,
750COM-UM006
750COM-UM007
Remote I/O 20-COMM-R
(2)
(2) This item has End-of-Life status.
—
(1)
RS485 DF1 20-COMM-S —
(1)
USB 1203-USB 1203-USB
