Rockwell Automation Publication 750-RM004A-EN-P - April 2018 121
Appendix A
Enclosure Information
Dimensions and Enclosure
Types
Enclosure and dimensional information based on the compatible migration
solutions are shown in the cross-reference tables.
The enclosure dimensions for both AC Input and DC Input PowerFlex 700S
frame 9…13 drives are the same, however, there are differences in weight
between AC and DC input types. See the PowerFlex 700S Drives with Phase II
Control Technical Data, publication 20D-TD002
, for enclosure weight data.
IMPORTANT The PowerFlex 700S frame 9 drive is usually mounted within an enclosure,
however, it can be wall-mounted per the catalog numbers shown. The
equivalent PowerFlex 755T product is supplied as a floor standing enclosure.
Consider the mounting and enclosure types that are used for your PowerFlex
700S frame 9 migration solution to ensure the PowerFlex 755T enclosed
product can be installed in the available space.
