Rockwell Automation Publication 750-RM004A-EN-P - April 2018 9
Preface
If the existing PowerFlex 700S drive has any of the above configuration
exceptions, contact an Authorized Rockwell Automation Distributor
specialist, Solution Partner, Recognized System Integrator, or Rockwell
Automation account manager to discuss engineered solutions for custom
migrations.
Follow this link for a list of Solution Partners and Recognized System
Integrators: http://www.software.rockwell.com/corporate/sp/
RASISearchResults.cfm?Programlevel=SP.
Before Migration
Follow these steps to be sure that your migration is successful.
• Upload and save the PowerFlex 700S parameters via Connected
Components Workbench™, Studio 5000 Logix Designer®, or
DriveExecutive™ software. If you cannot connect to the drive online,
manually record the parameter values.
• Record and label all power, digital, and analog I/O control wiring.
• Upload and save any network files and programmable logic controller
(PLC) programs.
General Information
See the Wiring and Grounding Guidelines for Pulse-width Modulated
(PWM) AC Drives Installation Instructions, publication DRIVES-IN001
, for
information regarding the topics listed below.
Wire/Cable Type
• General
•Input power
• Discrete drive I/O
• Analog signal and encoder
• Communication
Power Distribution
• System configurations
•AC line voltage
• Surge protection MOVs and common mode capacitors
• AC line impedance
• PowerFlex drives used with regenerative units
• DC bus wiring guidelines
Grounding
•Safety grounds
• Noise-related grounds
