Rockwell Automation Publication 750-RM004A-EN-P - April 2018 99
Drive Configuration Chapter 2
P842 Anlg Out2 Scale x:88
x:89
x:90
x:91
Anlg Out1 DataHi
Anlg Out1 DataLo
Anlg Out1 Hi
Anlg Out1 Lo
RW
P837 Anlg Out1 Value RO x:82 Anlg Out0 Val RO
P844 Anlg Out2 Value RO x:92 Anlg Out1 Val RO
(1) x = physical port location of I/O module
y = physical port location of I/O module
Table 56 - Analog I/O (Continued)
PowerFlex 700S PowerFlex 755T (With 2263C-1R2T I/O Module)
Parameter Display Name Read
/Write
Port:Parameter.Bit
(1)
Display Name Read
/Write
Table 57 - Digital I/O
PowerFlex 700S PowerFlex 755T (With 2263C-1R2T I/O Module)
Parameter Display Name Read
/Write
Port:Parameter.Bit
(1)
Display Name Read
/Write
P825…P830 Digital Inx Sel RW 0:103…191 Digital Input parameter assignment RW
P845, P846 Digital Out1 Sel, Dig Out1 Data RW x:20 TO0 Sel RW
P850, P851 Digital Out2 Sel, Dig Out2 Data RW x:30 TO1 Sel RW
P855, P856 Rly Out3 Sel, Rly Out3 Data RW x:10 RO0 Sel RW
(1) x = physical port location of I/O module
Table 58 - Communication
PowerFlex 700S 20-COMM-E EtherNet PowerFlex 755T Embedded EtherNet
Port 5, P4…P7 IP Addr Cfg 1, 2, 3, 4 RW 0:302…305 IP Addr Cfg 1, 2, 3, 4 RW
Port 5, P8…P11 Subnet Cfg 1, 2, 3, 4 RW 0:306…309 Subnet Cfg 1, 2, 3, 4 RW
P650 DPI In DataType RW —
P651…P658 DPI Data In RO 0:321…336 DL From Net 01…16 (Embedded EtherNet) RW
P659 DPI Out DataType RW —
P660…P667 DPI Data Out RW 0:340…355 DL To Net 01…16 (Embedded EtherNet) RW
