98 Rockwell Automation Publication 750-RM004A-EN-P - April 2018
Chapter 2 Drive Configuration
P802 Anlg In1 Scale RW x:51
x:52
10:1802/1809
10:1803/1810
10:1804/1811
10:2002/2009
10:2003/2010
10:2004/2011
Anlg In0 Hi
Anlg In0 Lo
Examples, analog scaling is applied to
reference source;
VRefA/B AnlgHi
VRefA/B AnlgLo
VRefA/B Mult
Trq RefA/B AnlgHi
Trq RefA/B AnlgLo
Trq RefA/B Mult
RW
RW
P803 Anlg In1 Offset RW —
P1093 Anlg In1 Loss Cnfg RW x:53 Anlg In0 LssActn RW
P806 Anlg In2 Data RO x:60 Anlg In1 Value RO
P807 Anlg In2 Value RO x:64 Anlg In1 Raw Val RO
P808 Anlg In2 Scale RW x:61
x:62
10:1802/1809
10:1803/1810
10:1804/1811
10:2002/2009
10:2003/2010
10:2004/2011
Anlg In1 Hi
Anlg In1 Lo
Examples, analog scaling is applied to
reference source;
VRefA/B AnlgHi
VRefA/B AnlgLo
VRefA/B Mult
Trq RefA/B AnlgHi
Trq RefA/B AnlgLo
Trq RefA/B Mult
RW
RW
P809 Anlg In2 Offset RW —
P1094 Anlg In2 Loss Cnfg RW x:63 Anlg In1 LssActn RW
P812 Anlg In3 Data RO y:50 Anlg In0 Value RO
P813 Anlg In3 Value RO y:54 Anlg In0 Raw Val RO
P814 Anlg In3 Scale RW y:51
y:52
10:1802/1809
10:1803/1810
10:1804/1811
10:2002/2009
10:2003/2010
10:2004/2011
Anlg In0Hi
Anlg In0Lo
Examples, analog scaling is applied to
reference source;
VRefA/B AnlgHi
VRefA/B AnlgLo
VRefA/B Mult
Trq RefA/B AnlgHi
Trq RefA/B AnlgLo
Trq RefA/B Mult
RW
RW
P815 Anlg In3 Offset RW —
P1095 Anlg In3 Loss Cnfg RW y:53 Anlg In0 LssActn RW
P831 Anlg Out1 Sel RW x:75 Anlg Out0 Sel RW
P838 Analog Out 2 Sel x:85 Anlg Out1 Sel RW
P835 Anlg Out1 Scale x:78
x:79
x:80
x:81
Anlg Out0 DataHi
Anlg Out0 DataLo
Anlg Out0 Hi
Anlg Out0 Lo
RW
Table 56 - Analog I/O (Continued)
PowerFlex 700S PowerFlex 755T (With 2263C-1R2T I/O Module)
Parameter Display Name Read
/Write
Port:Parameter.Bit
(1)
Display Name Read
/Write
