Rockwell Automation Publication 750-RM004A-EN-P - April 2018 97
Drive Configuration Chapter 2
P310 Output Freq RO 10:1 Output Frequency RO
P323 Fault Status 1 RO 10:461
13:240
Fault Status A (motor side)
Fault Status A (line side)
RW
RO
P324 Fault Status 2 RO 10:462
13:241
Fault Status B (motor side)
Fault Status B (line side)
RW
RO
P325 Fault Status 3 RO
P326 Alarm Status 1 RO 10:465
13:258
Alarm Status A (motor side)
Alarm Status A (line side)
RW
RO
P327 Alarm Status 2 RO 10:466
13:259
Alarm Status B (motor side)
Alarm Status B (line side)
RW
RO
P328 Alarm Status 3 RO 10:467
13:260
Type 2 Alarms (line side)
Type 2 Alarms (motor side)
RW
RO
P403 Voltage Class RW 0:33 Voltage Class Cfg RW
—0:35Duty Rating CfgRW
Default units are RPM only 0:46 Velocity Units RW
P414 Brake/Bus Cnfg RW 10:116 Bus Reg Mode A RW
P485 Motor Ctrl Mode RW 0:65 Pri MtrCtrl Mode (applies to Port 10) RW
P670 Logic Mask RW 0:41 Logic Mask Cfg RW
P671 Start Mask RW 0:42 Auto Mask RW
P672 Jog Mask RW 0:43 Manual Cmd Mask RW
P673 Direction Mask RW
P674 Fault Clr Mask RW
P677 Stop Owner RO 0:260 Stop Owner RO
P678 Start Owner RO 0:261 Start Owner RO
P679 Jog Owner RO 0:262 Jog Owner RO
P680 Direction Owner RO 0:263 Dir Owner RO
P681 Fault Clr Owner RO 0:264 Clear Flt Owner RO
Table 55 - Display, Status, Fault/Alarm, and Setup (Continued)
PowerFlex 700S PowerFlex 755T
Parameter Display Name Read
/Write
Port:Parameter.Bit Display Name Read
/Write
Table 56 - Analog I/O
PowerFlex 700S PowerFlex 755T (With 2263C-1R2T I/O Module)
Parameter Display Name Read
/Write
Port:Parameter.Bit
(1)
Display Name Read
/Write
P821 Analog I/O Units
(See also, Main Control Board, HW
switch S5)
RW x:45 Anlg In Type
(See also, module jumpers)
RO
x:70 Anlg Out Type RW
P800 Anlg In1 Data RO x:50 Anlg In0 Value RO
P801 Anlg In1 Value RO x:54 Anlg In0 Raw Val RO
