Rockwell Automation Publication 750-RM004A-EN-P - April 2018 39
Selection Considerations Chapter 1
Feedback Devices (s) Single Incremental Encoder, max
input frequency 500 kHz
(o) Second Incremental Encoder,
max input frequency 500 kHz
(o) Stegmann absolute encoder
(o) Resolver
(o) Single or Dual Incremental
Encoder, max input frequency 250
kHz
(o) Universal Feedback, Stegmann,
Heidenhain, SSI, Biss, Incremental
(o) Resolver (third-party AMCI
RD750)
Safety Devices (o) Hardwire Safe Torque Off (STO) (o) Hardwire, Safe Torque Off (STO)
(o) Integrated CIP Safety, Safe
Torque Off (STO)
(o) Hardwire Safe Speed Monitor
(SSM)
Torque/Brake Proving — (s)
Shear Pin (s) (s)
SynchLink™ (s) —
Load Observer — (s)
Inertia Adaption (s) (s) Acceleration Feedback, part of
Load Observer
PID Loop (s) (s)
Position Loop (s) (s)
Phase Lock Loop (PLL) (s) (s)
Integrated Motion — Not available at initial product
release
Drive Application Software (s) DriveLogix™ Not available at initial product
release
Table 9 - Enclosure Features
Description PowerFlex 700S, F9…F14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, F8…F12
Cat. No. 20D… Cat. No. 20G…
IP00, Open Chassis Yes, refer to Installation Manual,
publication PFLEX-IN020
Yes, refer to Technical Data,
publication 750-TD101 and
Installation Manual, publication
750-IN101
IP20, NEMA/UL Type 1
Approximate dimensions exclude
fan housings, handles, and so on.
Dimensions (H x D), Approx. (width
varies).
2100 MCC
2286 x 635 mm (90 x 25 in.)
See publication 20D-TD002 for
detailed dimensional data.
—
IP21, NEMA/UL Type 1
Approximate dimensions exclude
fan housings, handles, and so on.
Dimensions (H x D), Approx. (width
varies).
Rittal
2275 x 600 mm (89.6 x 23.6 in.)
See publication 20D-TD002
for
detailed dimensional data.
Rittal
2000 x 600 mm (78.7 x 23.6 in.)
See publication 750-TD101 and
publication 750-IN101 for detailed
dimensional data.
Table 8 - Control Specifications and Features (Continued)
Description PowerFlex 700S, F9…F14 PowerFlex 755TL/TR Drive and
PowerFlex 755TM Common Bus
Inverter, F8…F12
Cat. No. 20D… Cat. No. 20G…
