Rockwell Automation Publication 750-RM004A-EN-P - April 2018 137
Enclosure Information Appendix A
Figure 47 - DC Input Frame 11 PowerFlex 755TM Common Bus Inverter
1661
(65.4)
IP21, UL Type 1
2132
(83.9)
IP54, UL Type 12
2291
(90.2)
IP21, UL Type 1
676
(26.6)
IP54, UL Type 12
721
(28.4)
1200
(47.2)
1571
(61.9)
200
(7.9)
45
(1.8)
300
(11.8)
2132
(83.9)
676
(26.6)
Signal Cables -
Top Entry
