3-18 PowerFlex 700S Control Wiring
Table 3.I SynchLink Cables and Accessories
Table 3.J Fiber Optic Cable Assembly
Description Cat. No.
2 x 1 M Fiber Optic Link 1403-CF001
2 x 3 M Fiber Optic Link 1403-CF003
2 x 5 M Fiber Optic Link 1403-CF005
10 M Fiber Optic Link 1403-CF010
20 M Fiber Optic Link 1403-CF020
50 M Fiber Optic Link 1403-CF050
100 M Fiber Optic Link 1403-CF100
250 M Fiber Optic Link 1403-CF250
500 M Fiber Optic Bulk 1403-CFBLK
SynchLink Fiber-Hub, 1 input, Base 1751-SLBA
SynchLink Fiber-Hub, 4 output, “Star” Splitter 1751-SL4SP
SynchLink Bypass Switch 1751-SLBP/A
Specification
Connecting Cables 200/230 micron HCS (Hard Clad Silica)
• Versalink V-System
• Lucent Technologies,
• Specialty Fibers Technology Division
Maximum
Cable Length
300 meters with no more than one splice or one adapter
Minimum
Cable Length
1 meter
Minimum inside bend radius 25.4mm (1 in.) Any bends with a shorter inside radius can permanently
damage the fiber optic cable. Signal attention increases with
decreased inside bend radius.
Operating Wavelength 650 nm (Red)
Data Rate 5 Mbps
Maximum
Node Count
• 10 - Daisy Chain
• 256 - Star Configuration
