Appendix B
PowerFlex 700S Hi-Resolution (Stegmann)
Encoder Feedback Option
Specifications
Hi-Resolution (Stegmann) Feedback Option Card Specifications
Supported Encoders
Table B.A specifies which encoders are supported by the 700S
Hi-Resolution Stegmann Encoder Feedback Option module.
Important: Please note that encoders must be ordered as "Single Ended".
This will ensure that the RS-485 channel has the proper
termination network installed at the factory.
Table B.A Supported Stegmann Encoders
Consideration Description
Encoder Voltage Supply 11.5V dc @ 130 mA
Stegmann Feedback Sine/Cosine 1V P-P Offset 2.5
Maximum Cable Length 90m (295 ft)
Maximum Frequency
(Encoder Speed)
12.5 µs/cycle
(4687.5 RPM for encoders with 1024 sine cycles per revolution)
(9375 RPM for encoders with 512 sine cycles per revolution)
RS-485 Interface The Stegmann Feedback Option card obtains the following
information via the Hiperface RS-485 interface shortly after
power-up:
• Address
• Command Number
• Mode
• Number of turns
• Number of Sine/Cos cycles
• Checksum
Customer-I/O plug (P1) Allen-Bradley PN: S94262912
Weidmuller PN: BL3.50/90/12BK
Model Resolution Comment
SINCOS® SCS-60, SCS-70,
SCM-60, and SCM-70
512 sine cycles per revolution. SCM-60 and SCM-70 have built-in
mechanical turns counter.
SINCOS® SCS-KIT-101 and
SCM-KIT-101
1024 sine cycles per revolution. SCM-60 and SCM-70 have built-in
mechanical turns counter.
SINCOS® SRS-50, SRS-60,
SRM-50, and SRM-60
1024 sine cycles per revolution. SRM-50 and SRM-60 have built-in
mechanical turns counter.
