Frame 11 Installation 7-7
Minimum Mounting
Clearances
Operating Temperatures
Drive requires a minimum of 3900 m
3
/h (2295 cfm) of cooling air.
200 mm
(7.87 in.)
1000 mm
(39.3 in.)
PowerFlex Drive
Surrounding Air Temperature
Normal Duty Heavy Duty
700H 0 to 40 degrees C (32 to 104 degrees
F)
0 to 40 degrees C (32 to 104 degrees F)
700S 0 to 40 degrees C (32 to 104 degrees
F)
0 to 40 degrees C (32 to 104 degrees F)
