Rockwell Automation Allen-Bradley PowerFlex 700S Installation Manual

7-6 Frame 11 Installation
Removing Protective Covers
You must remove the protective covers to gain access to the power structure.
Task Description
Remove the four M5 Pozi-drive screws which secure the top and bottom protective covers
to the main front protective cover, then remove the top and bottom protective covers
Remove the four M5 Pozi-drive screws which secure the main front protective cover to the
drive, then remove the protective cover
