p-2 Overview
The following manuals are recommended for detailed PowerFlex 700S
information:
For Allen-Bradley Drives Technical Support:
Manual Conventions
• In this manual we refer to the PowerFlex 700H or 700S High Power
Adjustable Frequency AC Drive as; drive, PowerFlex 700H, PowerFlex
700S or PowerFlex High Power drive.
• To help differentiate parameter names and LCD display text from other
text, the following conventions will be used:
– Parameter Names will appear in [brackets].
For example: [DC Bus Voltage].
– Display Text will appear in “quotes.” For example: “Enabled.”
• The following words are used throughout the manual to describe an
action:
General Precautions
Title Publication
PowerFlex Reference Manual PFLEX-RM002
PowerFlex 700S User Manual 20D-UM001
Title Online at . . .
Allen-Bradley Drives Technical Support www.ab.com/support/abdrives
Word Meaning
Can Possible, able to do something
Cannot Not possible, not able to do
something
May Permitted, allowed
Must Unavoidable, you must do this
Shall Required and necessary
Should Recommended
Should Not Not recommended
!
ATTENTION: This drive contains ESD (Electrostatic
Discharge) sensitive parts and assemblies. Static control
precautions are required when installing, testing, servicing or
repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with
static control procedures, reference A-B publication 8000-4.5.2,
“Guarding Against Electrostatic Damage” or any other
applicable ESD protection handbook.
!
ATTENTION: An incorrectly applied or installed drive can
result in component damage or a reduction in product life.
Wiring or application errors, such as, undersizing the motor,
incorrect or inadequate AC supply, or excessive ambient
temperatures may result in malfunction of the system.
