Appendix A
Specifications
Category
PowerFlex 700H PowerFlex 700S
Agency
Certification
Listed to UL508C and CAN/CSA-C2.2 No. 14-M91. Listed to UL508C and CAN/CSA-C2.2 No. 14-M91.
Marked for all applicable European Directives
(1)
EMC Directive (89/336/EEC)
EN 61800-3 Adjustable Speed electrical power drive systems
Low Voltage Directive (73/23/EEC)
EN 50178 Electronic Equipment for use in Power Installations
Marked for all applicable European Directives
(1)
EMC Directive (89/336/EEC)
EN 61800-3 Adjustable Speed electrical power drive systems
Low Voltage Directive (73/23/EEC)
EN 50178 Electronic Equipment for use in Power Installations
The drive is also designed to meet the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 3.1 - Safety standards for Construction and Guide for
Selection, Installation and
Operation of Adjustable Speed Drive Systems.
IEC 146 - International Electrical Code.
The drive is also designed to meet the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 3.1 - Safety standards for Construction and Guide for
Selection, Installation and
Operation of Adjustable Speed Drive Systems.
IEC 146 - International Electrical Code.
(1)
Applied noise impulses may be counted in addition to the standard pulse train causing erroneously high [Pulse Freq] readings.
Category Specification
PowerFlex 700H PowerFlex 700S
Protection Drive 380/400 480V 500V 600V 690V 380/400 480V 500V 600V 690V
AC Input Overvoltage Trip: 611Vac 611Vac 611Vac 806Vac 806Vac 475Vac 570V ac 611V ac 690Vac
AC Input Undervoltage Trip: 235Vac 235Vac 235Vac 326Vac 326Vac Adjustable
Bus Overvoltage Trip: 911Vdc 911V dc 911V dc 1200V dc 1200V dc 675Vdc 810V dc 810Vdc 1013Vdc
Bus Undervoltage Shutoff/Fault: 333Vdc 333Vdc 333V dc 461V dc 461V dc Adjustable
Nominal Bus Voltage (Full Load): 517Vdc 621Vdc 645Vdc 776Vdc 890Vdc 540Vdc 648V dc 645V dc 810V dc
Heat Sink Thermistor: Monitored by microprocessor overtemp trip Monitored by microprocessor overtemp trip
Drive Overcurrent Trip
Software Overcurrent Trip: Calculated value, 105% of motor rated to 200% of
drive rated
105% of 3 sec. rating (158%-210%)
143% of 3 sec. rating (215%-287%)
Hardware Overcurrent Trip:
Instantaneous Current Limit:
360% of rated Heavy Duty current (typical)
—
360% of rated Heavy Duty current (typical)
—
Line transients: up to 6000 volts peak per IEEE C62.41-1991 up to 6000 volts peak per IEEE C62.41-1991
Control Logic Noise Immunity: Showering arc transients up to 1500V peak Showering arc transients up to 1500V peak
Power Ride-Thru: 15 milliseconds at full load 15 milliseconds at full load
Logic Control Ride-Thru: 0.5 seconds minimum, 2 seconds typical 0.25 seconds, drive not running
Ground Fault Trip: Phase-to-ground on drive output Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output Phase-to-phase on drive output
Environment Altitude: 1000 m (3300 ft) max. without derating 1000 m (3300 ft) max. without derating
Maximum Surrounding Air
Temperature without De-rating:
Based on drive rating, refer to Drive Frame chapters Based on drive rating, refer to Drive Frame chapters
Storage Temperature (all const.): –40 to 60 degrees C (–40 to 140 degrees F) –40 to 70 degrees C (–40 to 158 degrees F)
Atmosphere: Important: Drive must
not be installed in an area
where the ambient atmosphere contains volatile or
corrosive gas, vapors or dust. If the drive is not going
to be installed for a period of time, it must be stored in
an area where it will not be exposed to a corrosive
atmosphere.
Important: Drive must
not be installed in an area
where the ambient atmosphere contains volatile or
corrosive gas, vapors or dust. If the drive is not going
to be installed for a period of time, it must be stored in
an area where it will not be exposed to a corrosive
atmosphere.
Relative Humidity: 5 to 95% non-condensing 5 to 95% non-condensing
Shock:
Non-operational 15G peak for 11ms duration (±1.0 ms) 15G peak for 11ms duration (±1.0 ms)
Vibration: 2 mm (0.0787 in.) displacement, 1G peak
EN50178 / EN60068-2-6
2 mm (0.0787 in.) displacement, 1G peak
EN50178 / EN60068-2-6
