Rockwell Automation Allen-Bradley PowerFlex 755TS Series User Manual

158 Rockwell Automation Publication 750-TG101A-EN-P - June 2022
Chapter 6 Frame 7 Renewal Kits Installation
17. Disconnect the PE-B jumper wire from the power interface circuit board
(top left).
18. Disconnect the heatsink fan power wire-harness connector P2 from
connector J2 on the power interface circuit board (bottom left).
PE-B Jumper Wire
J2
PE-B IN
PE-B OUT
17
18
P2
