CE Conformance Requirements D-1
APPENDIX D
CE Conformance
Requirements
Conformity with the Low Voltage (LV) Directive and Electromagnetic
Compatibility (EMC) Directive has been demonstrated using
harmonized European Norm (EN) standards published in the
Official Journal of the European Communities. The MD60 AC drive
complies with the EN standards listed below when installed
according to the User Manual.
CE Declarations of Conformity are available online at:
http://www.reliance.com/certification/.
Low Voltage Directive (73/23/EEC)
• EN50178 Electronic equipment for use in power installations.
EMC Directive (89/336/EEC)
• EN61800-3 (Second Environment) Adjustable speed electrical
power drive systems Part 3: EMC product standard including
specific test methods.
General Notes
• If the top panel is removed or the optional conduit box is not
installed, the drive must be installed in an enclosure with side
openings less than 12.5 mm (0.5 in) and top openings less than
1.0 mm (0.04 in) to maintain compliance with the LV Directive.
Refer to figure 3.1.
• The motor cable should be kept as short as possible in order to
avoid electromagnetic emission as well as capacitive currents.
• The use of line filters in ungrounded systems is not
recommended.
• Conformity of the drive with CE EMC requirements does not
guarantee an entire machine installation complies with the CE
EMC requirements. Many factors can influence total
machine/installation compliance.
