Parameter Descriptions 9-27
9.3 Display Group Parameters
The output frequency present at terminals T1, T2, and T3 (U, V, and
W).
The value of the active frequency command. Displays the
commanded frequency even if the drive is not running.
Important: The frequency command can come from a number of
sources. Refer to section 6.5, Start and Speed
Reference Control, for more information.
The output current present at terminals T1, T2, and T3 (U, V, and
W).
The output voltage present at terminals T1, T2, and T3 (U, V, and
W).
d001 Output Frequency
Range: 0.0 to Maximum Frequency
Default: Read Only
See also: d002, d010, P034, P035
d002 Commanded Frequency
Range: 0.0 to Maximum Frequency
Default: Read Only
See also: d001, P034, P035, P038
d003 Output Current
Range: 0.00 to Drive Rated Amps x 2
Default: Read Only
See also: N/A
d004 Output Voltage
Range: 0 to Drive Rated Volts
Default: Read Only
See also: P031, A084, A088
