2-2 MD60 AC Drive User Manual
2.2 MD60 Drive Ratings, Model Numbers,
and Frame Sizes
Similar MD60 drive sizes are grouped into frame sizes to simplify
re-ordering and dimensioning. Refer to figure 3.2 for the dimensions
of each frame size.
Table 2.1 provides MD60 drive ratings, model numbers, and frame
sizes.
Table 2.1 – Drive Ratings, Model Numbers, and Frame Sizes
Drive Ratings
Model Number
Frame
SizeInput Voltage kW HP
Output
Current
115V, 50/60 Hz
1-Phase
0.2 0.25 1.5A 6MDVN-1P5101 A
0.37 0.5 2.3A 6MDVN-2P3101 A
0.75 1.0 4.5A 6MDVN-4P5101 B
1.1 1.5 6.0A 6MDVN-6P0101 B
230V, 50/60 Hz
1-Phase
With Integral
EMC Filter
0.2 0.25 1.5A 6MDAN-1P5111 A
0.37 0.5 2.3A 6MDAN-2P3111 A
0.75 1.0 4.5A 6MDAN-4P5111 A
1.5 2.0 8.0A 6MDAN-8P0111 B
230V, 50/60 Hz
1-Phase
No Filter
0.2 0.25 1.5A 6MDAN-1P5101 A
0.37 0.5 2.3A 6MDAN-2P3101 A
0.75 1.0 4.5A 6MDAN-4P5101 A
1.5 2.0 8.0A 6MDAN-8P0101 B
230V, 50/60 Hz
3-Phase
0.2 0.25 1.5A 6MDBN-1P5101 A
0.37 0.5 2.3A 6MDBN-2P3101 A
0.75 1.0 4.5A 6MDBN-4P5101 A
1.5 2.0 8.0A 6MDBN-8P0101 A
2.2 3.0 12.0A 6MDBN-012101 B
3.7 5.0 17.5 6MDBN-017101 B
460V, 50/60 Hz
3-Phase
0.37 0.5 1.4A 6MDDN-1P4101 A
0.75 1.0 2.3A 6MDDN-2P3101 A
1.5 2.0 4.0A 6MDDN-4P0101 A
2.2 3.0 6.0A 6MDDN-6P0101 B
3.7 5.0 8.7A 6MDDN-8P7101 B
