Accessories E-1
APPENDIX E
Accessories
E.1 Dynamic Brake Modules
Table E.1 – Dynamic Brake Modules
Drive Ratings
Model Number
1
1
The resistors listed in this table are rated for 5% duty cycle.
Input Voltage kW HP
Minimum
Resistance
(ohms)
120V 50/60 Hz
1-Phase
0.2 0.25 - AK-R2-091P500
0.75 1.0 - AK-R2-091P500
0.75 1.0 60 AK-R2-091P500
1.1 1.5 60 AK-R2-091P500
240V 50/60 Hz
1-Phase
0.2 0.25 - AK-R2-091P500
0.4 0.5 - AK-R2-091P500
0.75 1.0 60 AK-R2-091P500
1.5 2.0 60 AK-R2-091P500
240V 50/60 Hz
3-Phase
0.2 0.25 - AK-R2-091P500
0.4 0.5 - AK-R2-091P500
0.75 1.0 60 AK-R2-091P500
1.5 2.0 60 AK-R2-091P500
2.2 3.0 48 AK-R2-047P500
3.7 5.0 32 AK-R2-047P500
480V 50/60 Hz
3-Phase
0.4 0.5 - AK-R2-360P500
0.75 1.0 121 AK-R2-360P500
1.5 2.0 121 AK-R2-360P500
2.2 3.0 97 AK-R2-120P1K2
3.7 5.0 97 AK-R2-120P1K2
