9-32 MD60 AC Drive User Manual
The present value of the function selected in Testpoint Select
(A102).
The value present at the drive’s 0 - 10 V analog input.
The value present at the drive’s 4 - 20 mA analog input.
Displays the present operating temperature of the drive power
section.
d019 Testpoint Data
Range: 0 to FFFF
Default: Read Only
See also: A102
d020 0 - 10 V Analog Input
Range: 0.0 to 100.0%
Default: Read Only
See also: A110, A111
d021 4 to 20 mA Analog Input
Range: 0.0 to 100.0%
Default: Read Only
See also: A112, A113
d024 Drive Temp
Range:
0 to 120
0
C
Default: Read Only
See also: N/A
