Parameter Information B-9
Restart Restart Attempts 82 0…5 0
Allows the user to enable the SMC-Flex to
auto-restart for up-to 5 attempts, other than
an SCR overtemp or motor overload fault. The
start signal must remain active for a restart to
occur.
Restart Restart Delay 83 Secs 0…60 0
Provides a delay time between restart
attempts to allow for the condition to be
removed.
Linear List
Line Fault
Disable
84➂
0=Disable
1=Disable F1
2=DisableF41
3=Enable
Enable
This parameter gives the user the ability to
selectively disable specific fault codes such
as F1, F2, F3 and F41, F42, F43. These faults
are used to detect problems with incoming
power and the detection of appropriate zero
crosses (F1) or the firing of the SCRs based on
the current and voltage characteristics
associated with the SCR turning off (F41).
These faults can only occur during starting or
stopping and are usually related to the
incoming power condition.
Linear List Emergency Run 85
➂
0 = Disable
1=Enable
Disable
This parameter defeats all running faults and
is only effective in the “run” mode. It will not
override faults prior to starting (i.e. shorted
SCR). This parameter is reset to “off/disable”
when control power is recycled.
Linear List Current Loss 86
➂
0 = Disable
1=Enable
Enable
This parameter allows the user to override a
current loss fault. This is indicative of the
typical failure mode of a damaged CT.
Comm
Masks
Logic Mask 87 8-bit binary
0
Allows the user to enable or disable control
from various serial interface ports (DPI) with a
"0" setting. If a port is set to “1”, the port will
be allowed to control the SMC and will
produce a comm. fault if disconnected.
DataLinks Data In A1 88
0 16 bit Datalink
DataLinks Data In A2 89
0 16 bit Datalink
DataLinks Data In B1 90
0 16 bit Datalink
DataLinks Data In B2 91
0 16 bit Datalink
DataLinks Data In C1 92
0 16 bit Datalink
DataLinks Data In C2 93
0 16 bit Datalink
DataLinks Data In D1 94
0 16 bit Datalink
DataLinks Data In D2 95
0 16 bit Datalink
DataLinks Data Out A1 96
0 16 bit Datalink
DataLinks Data Out A2 97
0 16 bit Datalink
DataLinks Data Out B1 98
0 16 bit Datalink
DataLinks Data Out B2 99
0 16 bit Datalink
DataLinks Data Out C1 100
0 16 bit Datalink
DataLinks Data Out C2 101
0 16 bit Datalink
DataLinks Data Out D1 102 0 16 bit Datalink
DataLinks Data Out D2 103
0 16 bit Datalink
Table B.1 Parameter List (Continued)
Group
Parameter
Name
Parameter
Number
Units
Min./
Max.
Default
Settings
Parameter Description
User
Settings
➂ This parameter is not viewable without entering a special password in Firmware versions 4.001 or earlier. Contact Rockwell Automation technical support if you have
Version 4.001 firmware or earlier and need to access this parameter.
