Rockwell Automation Publication 6200-UM001C-EN-P - July 2018 17
Chapter 3
Install the Thin Client or Computer
Before You Begin
Before you unpack your VersaView® 5000 ThinManager® thin client or
industrial computer, inspect the shipping carton for damage. If damage is
visible, immediately contact the shipper and request assistance. Otherwise,
proceed with unpacking.
Keep the original packing material in case you need to return the VersaView
thin client or computer for repair or transport it to another location. Use both
the inner and outer packing cartons to provide adequate protection for
equipment returned for service.
Parts List
VersaView thin clients or computers ship with the following items.
Topic Page
Before You Begin 17
Parts List 17
Installation Precautions 18
Installation Guidelines 19
Mounting Clearance Requirements 20
Dimensions 21
Required Tools 23
Install the Thin Client or Computer 23
Connect Peripherals 28
Connect Power 29
Item Description
Hardware • Mounting clips
(1)
• DC terminal block
(2)
• AC-to-DC power adapter, cat. no. 6200V-MPS5
(3)
• Four rubber mount pads
(4)
(1) Shipped only with VersaView thin client and industrial computers with integrated display models.
(2) DC terminal block does not ship with the cat. no. 6200T-BA ThinManager thin client model.
(3) Shipped only with the cat. no. 6200T-BA ThinManager thin client model.
(4) Shipped only with non-display industrial computers and non-display ThinManager thin client models.
Documents • VersaView 5100 Industrial Monitors, VersaView 5000 Thin Clients, Industrial Computers,
and Accessories Product Information, publication 6200-PC001
• VersaView 5000 Thin Client and Integrated Display Industrial Computers Cutout Template,
publication 6200-DS001
(1)
