Rockwell Automation Publication 6200-UM001C-EN-P - July 2018 23
Install the Thin Client or Computer Chapter 3
Required Tools
These tools are required to install all VersaView 5000 models:
#2 cross-head screwdriver
Panel cutout tools (for wall and panel mounting)
2 mm Allen wrench (for mounting clips on integrated display models)
Drill motor and drill bit (for wall, machine, and table mounting)
T10 Torx key or screwdriver (to install optional brackets)
Anti-static wriststrap
Install the Thin Client or
Computer
The computers support the following mounting options:
Panel mount (for integrated display models)
Wall mount (for non-display models)
Panel Mounting Guidelines
Observe these guidelines when you install an integrated display thin client or
computer in a panel.
Remove all electrical power from the panel before you make the cutout.
Confirm that there is adequate space behind the panel. For specific
information, refer to Mounting Clearance Requirements
on page 20.
Cut supporting panels to specifications before installation. Take
precautions so metal cuttings do not enter components already installe
d
in
panel.
The supplied mounting hardware accommodates panel thickness
between 1.5…6 mm (0.06…0.24 in.).
Make sure the area around the panel cutout is clear.
The only acceptable mounting position is in the horizontal positi
on
w
ith the I/O ports at the bottom.
For VESA mounting of non-display thin clients or computers, th
e
i
nstallation must provide sufficient mechanical stability to minimize the
effects from vibration and shock. The mounting means must be firm
ly
at
tached to the supporting surface with the appropriate hardware.
TIP All non-display models ship with a factory-installed mounting plate for
wall mounting, except for cat. nos. 6200T-RC and 6200T-RE.
Instructions for other available mounting plates and mounting options
are detailed in Appendix A, Install Accessories
, starting on page 51.
ATTENTION: Failure to follow these guidelines can result in personal
injury or damage to the panel components.
IMPORTANT VESA mounting reduces the computer IP rating from IP65 to IP20.
