Rockwell Automation Publication 6200-UM001C-EN-P - July 2018 19
Install the Thin Client or Computer Chapter 3
To comply with EN 55024 and EN 55032, use the following for cable types.
Installation Guidelines
Follow these guidelines to make sure your VersaView thin client or industrial
computer provides service with excellent reliability:
• The installation site must have sufficient power.
• In dry environments, static charges can build up easily. Proper grounding
of the thin client or computer helps to reduce static discharges, which
can cause shock and damage electronic components.
• The ambient air temperature must not exceed the maximum operating
temperature in Tab le 3
.
Table 3 - Maximum Operating Temperature Ranges
Cable Type Required Attribute Cable Type Required Attribute
LAN
Shielded
Line-out
Unshielded
USB Line-in
Serial RS-232 Microphone
DVI DC power
DisplayPort AC power Unshielded
(1)
(1) For the applicable power adapters, see the Power Connection table rows in Connect Peripherals on page 28.
Mini-DisplayPort
HDMI
VGA
ATTENTION: For applications with an AC power source, the shipped
or optional AC-to-DC power adapter must be plugged into a
grounded outlet to maintain an electrically safe installation.
VersaView Model Cat. Nos. Temperature, max
5200
ThinManager thin client
Non-display 6200T-BA 0…50 °C (32…122 °F)
6200T-KB 0…55 °C (32…131 °F)
6200T-RC, 6200T-RE 0…45 °C (32…113 °F
6200T-NA -20…+60 °C (-4…+140 °F)
Display 6200T-xxWA 0…50 °C (32…122 °F)
5400 Industrial Computers Non-display 6200P-NSxA1 -20…+60 °C (-4…+140 °F)
Display 6200P-xxWS3x1 0…50 °C (32…122 °F)
IMPORTANT VersaView thin clients and industrial computers can operate at a
range of extremes. However, the life span of any electronic device is
shortened if you continuously operate it at its highest rated
temperature, which includes the touch screen and LCD panel.
