Rockwell Automation Publication 6200-UM001C-EN-P - July 2018 57
Install Accessories Appendix A
For VersaView 5200 ThinManager Thin Client Single Display Model
(cat. no. 6200T-BA)
1. Follow the steps for Pre-configuration on page 52.
2. With a Torx 10 key or screwdriver, remove the four screws that secure
the factory-installed mounting plate to the back of the thin client.
3. Install the new backplate from the VESA mounting kit
(6200V-BXVESA2) with the four screws that you removed in step 2.
4. With the four supplied screws, install the VESA mounting bracket
(cat. no. 6200V-BXVESA2) to the VESA mounting arm.
5. Remove the two screws (A) from the top of the thin client.
To Next Page
