ROEL CERBER C52 - Default Zone Type and Attribute Values; Defining Zone 1 [01] Procedure

35
ATTRIBUTES
2
set:
Zone LEDs
ON
OFF
Remarks:
10/16, obtained by doubling the low zones), copy these attributes from the corresponding low zones;
2. by default, these 2
nd
and 3
rd
attributes from the above set, are disabled for all zones.
After establishing these 2
nd
set of attributes for the selected zone, press [#] key to
confirm. The keypad buzzer will sound 6 beeps and exit this section, waiting for a new
command to enter another section or to exit the programming menu.
Default values of the types and attributes for 1 to 10/16 zones
Active Attributes:
zone
number
zone type
siren
alarm
siren
sound
type
bypass
enable
activate
chime
allows
forced
arming
slow
detection
(300ms)
Belong to
1
-st
partition
Belong to
2
-nd
partition
1
[01] “delayed”
“audible”
“steady”
yes
yes
yes
yes
yes
no
2
[03] “follower”
“audible”
“steady”
yes
no
yes
yes
yes
no
3
[04] “instant”
“audible”
“steady”
yes
no
no
yes
yes
no
4
[04] “instant”
“audible”
“steady”
yes
no
no
yes
yes
no
5
[04] “instant”
“audible”
“steady”
yes
no
no
yes
yes
no
6
[00] “not used”
“silent”
“pulsing
”
no
no
no
no
no
no
7
[00] “not used”
“silent”
“pulsing
”
no
no
no
no
no
no
8
[00] “not used”
“silent”
“pulsing
”
no
no
no
no
no
no
9
[00] “not used”
“silent”
“pulsing
”
no
no
no
no
no
no
10
[00] “not used”
“silent”
“pulsing
”
no
no
no
no
no
no
SECTION [01] - DEFINING ZONE 1
While the panel is within the “main programming menu”, to program zone 1 parameters
select section [01], then enter the following sequence:
|__|__|[ATTRIBUTES
1
][#][ATTRIBUTES
2
][#]
where [__][__] is the 2-digit number for type of zone 1, and ATTRIBUTES
1
& ATTRIBUTES
2
are 1&2 sets of attributes
for zone 1.
See 1 to 10/16 zone defining described in the previous paragraphs.
After entering the 2 digits for the zone type, the keypad buzzer will sound 3 beeps and
the Zone LEDs will turn ON / OFF according to the ATTRIBUTES
1
set of zone 1. Press any of
1 to 8 keys according to your desired selection of attributes to have them activated
/ deactivated.
After choosing the first set of attributes, press [#] key to confirm and the keypad
buzzer will sound 3 beeps. Then, Zone LEDs will turn ON / OFF according to the ATTRIBUTES
2
set of zone 1. Press any of 1 to 5 keys according to your desired selection of
attributes to have them activated / deactivated.
After choosing the second attribute set, press [#] key again to confirm. The keypad
buzzer will sound 6 beeps, exit the section and come back to the “main programming menu”,
waiting for a new command to enter another section or to exit the programming menu.
To exit the programming menu, press [#] key again.
SECTION [02] - DEFINING ZONE 2
Do the same as for zone 1.
SECTION [03] - DEFINING ZONE 3
Do the same as for zone 1.
SECTION [04] - DEFINING ZONE 4
Do the same as for zone 1.
SECTION [05] - DEFINING ZONE 5
Do the same as for zone 1.
SECTION [06] - DEFINING ZONE 6
