ROHS Performance Series - System Installation; Package Contents and Device Connection Guide

9
Model
8 Channel Performance DVR
16 Channel Performance DVR
Video
In
8 BNC (Loop-out option*)
16 BNC (Loop-out option*)
Out
1 VGA, 1 CVBS (Dual Display)
Audio
In
8 RCA (Line in) – Option*
Out
1 RCA (Line Out)
Device
Sensor In
4 TTL (3+Emergency)
Alarm Out
2 Open Collector Output
I/O Interface
RS232, RS485, USB x 2
Display
Speed
Real Time
Resolution
720 x 480 (NTSC)
Split Screen
1,4,6,9,PIP,Digital Zoom
1,4,6,8,9,13,16,PIP,
Digital Zoom
Recording
Compression
H.264 Codec
Speed /
Resolution
240fps@CIF(NTSC)
240fps@Half D1(NTSC)
120fps@D1(NTSC)
480fps@CIF(NTSC)
240fps@Half D1(NTSC)
120fps@D1(NTSC)
Picture Quality
Very High, High, Standard, Low
Mode
Time-lapse, Event, Time & Event, Emergency (Panic)
Playback
Display
1, 4, 6, 9, Digital Zoom
1,4,6,8,9,13,16,Digital Zoom
Search Mode
Calendar Search, Event Search, Text-In Search, Go to Time
Playback Mode
Multi Channel Normal & Reverse Play,
RW & FF ( x2, x4, x8, x16, x32), Frame to Frame, Pause
Network
Interface
Ethernet (10/100 Base)
Protocol
TCP/IP, HTTP, DHCP, ADSL(PPPoE), RTP/RTSP
Application
Live, Playback, Setup, Notification (Callback, E-Mail)
Web Browse
Internet Explorer 7 or higher
Mobile Support
iPhone, Android Phone (Real Streaming)
Storage
2 x SATA HDD
Backup
External HDD(USB), External USB Memory
Control
Front Panel Button, USB Mouse port,
IR Remote Controller, Joystick Controller port
OSD
Graphic User Interface (Multilingual)
Approval
FCC, CE, KCC
ROHS
ROHS Compliance
Power Consumption
DC12V, 3.33 (40W)
Operating Temperature
41°F~104°F
Operating Humidity
0%~80% / non-condensing
Dimension
13.39(W)x2.64(H)x10.43(D)inch
Weight
4.4lb (without HDD)
* Requires optional accessory connector(s). Please ask about this to your supplier.
